Ro Water Treatment Machinery for Drinking Water Equipment Plant Filter Purifier Purify Mineral Water Treatment System

Product Parameters*Typical pure water treatment ProcessingRaw water pump - Quartz sand filter - Activated carbon filter- Sodium ionexchange→Precision filter -High-pressure pump-Reverse osmosis system -UV sterilizer→Ozone sterilizer →Finished Water tank
1. Raw water pump: provide the pressure to Quartz sand filter/active carbon filter2. Quartz Sand filter: get rid of turbidity, suspended matter, organic matter, colloidand so on
3. Activated Carbon filter: Remove the color, free chloride, organic matter, harmfulmatter and so on4. Sodium ion exchanger: Get rid of calcium and magnesium ions in original /source water, reduce water hardness.5. Precision filter: prevent any deposition of large Particles, most of the bacteriaand viruses into the RO membrane, The accuracy is 5um, for holding back anylarge particulates such as large iron, dust, suspended matter, impurity.6. High pressure pump-- Provide the high pressure to RO membrane(at least 2.0Mpa).
7. RO system-- main part of pure water treatment plant. The desaltation rate up to99%, it is capable of removing over 99% of ions, bacterias, particles and 98% oforganic.
8. UV sterilizer -- kill some bacteria that may also pass through the reverseosmosis
9.Ozone sterilizer -- Use ozone Kill bacteria not killed by UV10.Finished water tank -- For filter water storageProduct DetailsRO water treatment systemThe principle of reverse osmosis is to apply a certain pressure to water, so that water molecules and ionic mineral elements pass through the reverse osmosis membrane. However, most of the inorganic salts (including heavy metals), organic matter, bacteria and viruses dissolved in the water cannot pass through the reverse osmosis membrane, thereby strictly separating the permeated pure water from the impermeable concentrated water, reverse osmosis is a selective membrane that can only pass through the water. The process of separating the water molecules in the water from the solute cannot be carried out by the selective permeability of the solute, and the pressure higher than the osmotic pressure is used as the driving force.Reverse osmosis internal structure PP cotton, compressed activated carbon filter element, activated carbon: 5 micronpore size filter element, remove residual sediment, rust and other tiny impurities in water, further remove residual chlorine, odor and solid impurities in water; it can better improve water quality smell.Ultrafiltration water treatment systemThe ultrafiltration water treatment equipment can intercept particles and impurities with a diameter of 0.002-0.1 um through the micropore screening on the membrane surface, and can effectively remove colloids, silicon, proteins,microorganisms and macromolecular organic matter in water. lt can be widely used in the separation, concentration and purification of substances. The ultrafiltration process has no phase inversion, does not require heating, operates at room temperature, saves energy, and is especially suitable for the separation of heat-sensitive substances. The ultrafiltration process is simple, there are few supporting devices, the operation is simple and the maintenance cost is low.Lowest investment cost and easy cleaning.To produce mineral water--Substances with a molecular weight of 3x10000-1x10000 can be screened through the micropores on the membrane surface. When the water to be treated passes through the membrane surface at a certain flow rate with the help of external pressure, water molecules and solutes with a molecular weight of less than 300-500 pass through the membrane while particles and macro molecules larger than the membrane pores are retained due to the sieving effect. thereby purifying the water.Cooperation BrandProduct Categories

Product Gallery
