JH21 315 Ton C Frame Mechanical
Contact the supplier first
Confirm product spec, exact USD price, MOQ and lead time. Then paste their quoted price below to get a precise landed estimate.
- [email protected]
- 86-21-62828630
- WhatsApp: 8613817120700
- worldshm.com
- 432 Huaihai West Road, Shanghai, China
- Avg response: within_1_hour
Ship the goods to our Shenzhen warehouse
Ask the supplier to deliver to our hub below. We consolidate, inspect and ship to South Africa for you.
Estimate the SA delivery cost
Paste the supplier's quoted price + your shipment specs. Results update live below.
Estimated landed cost in South Africa
Enter the supplier price + dimensions above to see the breakdown.
Live estimate. Values recalculate as you type — Product × FX + customs duty & handling + 15% VAT + freight. Variance vs final binding quote is typically < 5% and only changes if the supplier's pro-forma differs from your inputs.
How Class B sourcing works on BestDealz
One platform · Verified suppliers · Trade Assurance · End-to-end logistics — fully landed in SA
Message the supplier
On-platform chat — get a factory pro-forma with delivery to our Shenzhen consolidation centre.
Submit the pro-forma
We calculate sea/air freight, customs, 15% VAT and last-mile in ZAR — precise quote in < 24 hours.
Pay & we ship
One all-in payment in Rand under Trade Assurance. We handle SARS clearance and SA delivery.
Door-to-door
Goods land at your address in 60–70 days. Inspect on arrival.
Product Gallery
1. Steel plate welded c frame body, heat treatment, produced by cnc boring and milling center, high rigidity and precission
2. Wet type pneumatic clutch with safety solenoid valve, lower noise and longer service life.
3. Best quality gears, bushes, cylinders, link rods and ball screw ensure the high performance, high reliability and longer service life.
4. Hydraulic overload protected system is standard equipped. The press will stop with oil pressure release if overload to protect the press and the die. It is easy to reset to normal status.
5. PLC control, Omron or Panasonic brand, high quality with global warranty.
6. Double hands control buttons, touch screen control panel, cam controller with encoder.
7. Slide adjust motor is equipped on the back of the slide. This position is better to protect the motor and the press is more compact in this way. The slide is motorized adjusted with digital displayer.
8. Center auto grease lubrication system is standard equipped and the lubrication frequency can be setted with the touchscreen. In the meanwhile, manual thin oil lubrication system is equipped too.
| ITEM | CODE | UNIT | JH21-315 | |
| Nominal Capacity | Pe | KN | 3150 | |
| Slide Stroke | S | mm | 220 | |
| Slide Strokes | Fixed | spm | Times/min | 30 |
| Variable(optional) | spm | Times/min | 20-30 | |
| Max. Die Shut Height | H2 | mm | 500 | |
| Die Shut Height Adjustment | t | mm | 120 | |
| Throat Depth | C1 | mm | 450 | |
| Distance Between Uprights | d1 | mm | 980 | |
| Slide Bottom Size | FB | b | mm | 700 |
| LR | a | mm | 950 | |
| Shank Hole Size | Diameter | d | mm | 70 |
| Depth | I | mm | 130 | |
| Bolster Size | FB | D | mm | 880 |
| LR | C | mm | 1540 | |
| Thickness | H3 | mm | 190 | |
| Bed Opening Hole Diameter | ¢ | mm | 270 | |
| Overall Dimensions | FB | A | mm | 2720 |
| LR | B | mm | 1680 | |
| Height | H | mm | 3865 | |
| Motor Power | KW | 30 | ||
| Weight(approximate) | kg | 26600 | ||
