Product Gallery
Reinforced type gear, transmission torque large
B1 type optional2-speed motor, spindle speed range widely.
Application:
Widely used in single or batch is machinery manufacturing industry; instrument; building decoration and repair department.
Product main technical Specifications:
Specifications | ZX7025 | ZX7032 | ZX7045 |
Max. Drilling capacity (mm) | 25 | 31.5 | 45 |
Max. face mill capacity (mm) | 63 | 80 | 80 |
Diameter of vertical milling (mm) | 13 | 22 | 28 |
Diameter of column (mm) | / | / | / |
Spindle travel (mm) | 110 | 130 | 120 |
Distance spindle axis to column generating line(mm) | 240 | 202 | 260 |
Max. Distance spindle nose to table (mm) | 510 | 460 | 475 |
Spindle taper | MT3 | MT3 | MT4 |
Spindle speeds range (r/min) | 290~2150 | 100~2150 | 95~1600 |
Spindle speeds series | 5 | 12 | 6 |
Spindle feeds (mm/r) | / | / | / |
Dimension of worktable surface (mm) | 555×195 | Standard : 730x210 select: 820x240 | Standard : 730x210 select: 820x240 |
Table travel (mm) | 240×140 | Standard :450×170 select: 540x170 | Standard :450×170 select: 540x170 |
Dimension of base (mm) | / | / | / |
Overall height (mm) | 1130 | 1100 | 1050 |
Main motor (W) | 750 (6P) | Single-phase:1100 Three-phase:1500 | Single-phase:1100 Three-phase:1500 |
Coolant motor (W) | / | / | / |
G.W/N.W(Kg) | 190/160 | 285/250 | 318/278 |
Packing dimension (cm) | 87×67×102 | 97×77×124 | 97×77×116 |
