Product Gallery
|
Model number |
CPU |
4K |
LAN |
COM |
USB2.0 |
USB3.0 |
SSD |
Memory(MAX) |
Power |
|
4 inch motherboard M600SE |
3955U, Skylake 6Gen i3,i5,i7 |
support |
1 |
6 |
5 |
4 |
1*MSATA 1*2.5 inch SSD /HDD |
1*NB-DDR4 16G |
+12V~19V Wide voltage supply |
|
2 |
6 |
5 |
4 |
||||||
|
4 inch motherboard M700SE |
3865U, 3965U, Kabylake 7Gen i3,i5,i7 |
support |
1 |
6 |
5 |
4 |
|||
|
2 |
6 |
5 |
4 |
|
Size |
4 inch motherboard 165mm*115mm*18mm(With radiator 165mm*115mm*31mm) |
||
|
CPU processor |
M600SE |
3855U,3955U, Skylake i3-6100U,i5-6200U,i7-6500U |
|
|
M700SE |
3865U,3965U, Kabylake i3-7100U,i5-7200U,i7-7500U |
||
|
Chipset |
Single Chip Integrated in CPU |
||
|
Power Supply |
1*DC_IN |
DC head diameter is 2.5MM, supporting 12V ~ 19V wide voltage power supply Motherboard power consumption: about 35W. recommend to use 12V5A or above power supply. |
|
|
Memory |
1*NB-DDR4 supports 2133/2400MHz memory, maximum 16G |
||
|
Display function |
M600SE |
Intel HD Graphics 510/520 Graphics Controller |
Supports single-display, double-display/triple-display replication, double-display/triple-display expansion, and single-display under DOS |
|
M700SE |
Intel HD Graphics 610/620 Graphics Controller |
||
|
1*VGA DB15 interface |
Supporting maximum resolution 1920*1200@60HZ |
||
|
1*HD-MI 1.4 interface |
Supporting maximum resolution 4096*2304@24/30HZ |
||
|
1*LVDS Pin |
Supporting maximum resolution 1920*1080@60HZ (2*15Pin,2.0mm) |
||
|
Network function |
1*LAN/2*LAN |
RTL8111H gigabit network card chip supports network wake-up and PXE diskless startup functions |
|
|
1*Mini-PCIE interface |
Support WIFI/3G/4G/Bluetooth, etc. |
||
|
Hard disk function |
1*SATA1 interface |
Standard SATA3.0 Hard Disk Interface, Maximum Transmission Speed 6.0 Gbps |
|
|
1*MSATA interface |
Support MINI_SATA disk and MSATA3.0 |
||
|
Audio function |
Integrated Realtek ALC662 HD Digital Audio Decoder, 6-Channel High Fidelity Audio Controller |
||
|
Running environment |
Working temperature: - 20 ~60 C; Working humidity: 5%~95% relative humidity, no condensation |
||
|
BIOS |
AMI BIOS,Supporting power on,Power-On by Alarm,Intelligent Recognition of Remote Switchgear Equipment. |
||
|
Watch Dog |
Watchdog programming, supporting hardware reset function (256 levels, 0-255 seconds) |
||
|
Operating system |
Support Win 10,Win 8,Window 7,Linux. |
||
Technical specifications
| socket type | on board |
|---|---|
| application | industrial control PC, Advertising machine |
| memory type | DDR4, 1*DDR4 memory channel, up to 16GB RAM. |
| cpu type | Intel |
| chipset | Intel high speed chipset on CPU |
| ports | Display Port, Ethernet, SATA, USB 2.0, USB 3.0, VGA, Wi-Fi |
| form factor | 4.0 inch professional structure, (L*W)165*115mm |
| maximum ram capacity | 16 GB |
| memory channel | Double |
| graphics card type | Integrated Intel HD Graphics 510/520/610/620 on CPU |
| memory bank | 1 * DDR4 SODIMM |
| with cpu | Yes |
| SKU | 62109376913 |
